Conventional Outdoor Fireplace
ADD TO WISHLIST
FireRock Conventional Outdoor Fireplace Kits
An outdoor fireplace is the perfect centerpiece to incorporate when designing an outdoor space that features comfort and style. It will bring life to the space and guests will love to gather around it.
FireRock’s conventional outdoor fireplace system is expertly designed to provide a full masonry system that is easy to install. With 3 sizes available, our conventional outdoor firebox has a straight back wall and straight opening for a clean look.
- Available sizes: 30″, 36″ and 42″
- Traditional-style firebox with straight back wall
- Fireplace Kit includes 2-3 feet masonry chimney
- Both firebox and chimney system components are delivered on a single pallet
- Compliances: UL 127
- In the event that additional dimension is required, build out with concrete masonry units (CMUs) or metal framing material
- Approved for outdoor use only
Click Here to View the Brochure
Having trouble choosing the right fireplace for your outdoor space? Check out our how-to guide for 5 common questions you should be asking yourself to ensure your fireplace plans suit your needs, taste and your home.
Click Here for the Installation Manual
Specifications
FIREROCK OUTDOOR CONVENTIONAL MODEL DIMENSIONS
All measurements listed are based on dry stack units before firebrick is installed. Dimensions are nominal and are given for design and framing reference only. Please consult installation manual for all details and requirements before making final design layout decisions.
| MODEL | WIDTH | HEIGHT | DEPTH | DAMPER | WEIGHT | ||||||
| Opening | Firebox Rear |
Overall | Opening | Firebox | Smoke Chamber |
Overall | Firebox | Overall | |||
| 30″ Outdoor Conventional | 32.5″ | 22″ | 38″ | 25.125″ | 28.875″ | 22.375″ | 75.25″ | 22.5″ | 28.5″ | N/A | 1,550 lbs |
| 36″ Outdoor Conventional | 38.5″ | 28″ | 44″ | 33.75″ | 37.5″ | 22.375″ | 83.875 | 22.5″ | 28.5″ | N/A | 1,860 lbs |
| 42″ Outdoor Conventional | 44.5″ | 34″ | 50″ | 33.75″ | 37.5″ | 31.5625″ | 105.0625″ | 22.5″ | 28.5″ | N/A | 2,400 lbs |
| Chimney Diameter | Masonry Chimney: 15″ UL 103 Metal Chimney: 12″ (30″ model only) or 14″ |
||||||||||
| Total Chimney Height | Minimum 30” and 36” models – 24” 42” model – 36” Maximum 30” model – 16’ 4” 36” model – 17’ 42” model – 17’ 9” *For 30” and 36” fireplaces, 2’ of chimney block (4 pieces) are provided. For the 42” unit, 3’ (6 pieces) are included in the kit. Additional chimney block can be added to achieve the desired height as long as maximum heights are followed. |
||||||||||
